39
6.1.2 Technical Data
Supply Voltage
24 V from Master
Distance to master
Max 3 m
Enclosure
IP 21
Ambient temperature range
0 to 40°C
Communication Frequency
868 MHz
Communication distance
Up to 30m inside building and 100m
line of sight
Connection of master and receiver
The receiver is connected to the master or the add on module using
the included cable. Max distance between the master/add on module
and receiver is 3m. Up to 5 receivers can be connected, either in a
daisy chain or in parallel.
Positioning
Do not place the receiver inside a metal box. In case of
communication problems it may be necessary to move the location of
the receiver, or to add an additional receiver.
Configuring
Connect the receiver to the master, and the system will reconfigure
itself for wireless operation.
36. Connection of Master And Wireless Receiver
REHAU BA
Master Controller
REHAU Wireless
Receiver (RC)
