Rehau VACUCLEAN 2000 - Block Diagram

35
5.9.3
Block diagram
Fig. 5-44: Block diagram control cable
1 Cable connection, e.g. through lamp-wire
connectors
A Under-roof floor
2 Suction socket B Upper level
3 Control cable, 2-core C Ground floor
4 Control module D Cellar level
5 Central vacuum unit
