HOME
A default configuration for the MACH-Pro(Web)Com controller can be quickly assigned in
the Home group.
FIGURE 41: HOME GROUP
3 Select the appropriate expansion module type for each module address (MPP-
IO, MPP-I, or MPP-O). Any combination of expansion modules may be entered
without exceeding the maximum I/O count of the controller.
4 Click the OK button to close the I/O-Net Configuration dialog box.
5 In the Port Setup dialog box, click the Send button to send the new
configuration to the MACH-Pro(Web)Com. Be aware that sending the
configuration will cause the controller to reset.
