Reliance electric PSC PC-2 - Standard Settings for Operation of the PSC Console

3-2
PSC Console PC-2
3.2 Standard Settings for Operation of the PSC Console
ATTENTION: Changing the settings of the PSC Console may cause
malfunction of the system. Exercise extreme caution when the setting
of the PSC Console must be changed. Note that the settings of the
PSC Console will be maintained even when the power to the Console
is disconnected.
The following are the standard settings of the PSC Console for communication with
the PSC3000, PSC4000 or PSC5000 System.
• Baud rate : 4800 bps
• Code used : JIS8
• Parity bit : Even
• Stop bit : 1
!
