4.3 Operation of the PSC Console in the MONITOR Mode
The MONITOR Mode must be selected to monitor the values of the control
variables. This section describes how to select the MONITOR Mode and how to
operate the PSC Console in the MONITOR Mode.
4.3.1 Selection of the MONITOR Mode
To select the MONITOR Mode of the PSC Console, press the MONITOR key. The
following display will appear on the PSC Console.
M O N I T O RSystem Line
Display Line 1
Display Line 2
Display Line 3
4.3.2 Keys Usable in the MONITOR Mode
Figure 4.2 shows the keys usable in the MONITOR Mode. Only the keys grey-
colored in the figure can be used.
RUN MONITOR PROGRAM P-ROM SHIFT
ALLCLR VRFY MON DATA NO
123
456
789
0 CLR
C
E
PLAY
RCD
TEST
ENTER
DEL
+/
In the MONITOR Mode, only the grey-colored keys shown in this figure can be used.
Figure 4.2 – Keys Usable in the MONITOR Mode
