Reliance electric PSC PC-2 - Operation of the PSC Console in the RUN Mode; Selection of the RUN Mode; Keys that Can be Used in the RUN Mode; Figure 4.1 - Keys that Can be Used in the RUN Mode

4-2
PSC Console PC-2
RUN MONITOR PROGRAM P-ROM SHIFT
ALLCLR VRFY MON DATA NO
123
456
789
0 CLR
C
E
PLAY
RCD
TEST
ENTER
DEL
+/
In the RUN Mode, only the grey-colored keys shown in this figure can be used.
Figure 4.1 – Keys That Can be Used in the RUN Mode
4.2 Operation of the PSC Console in the RUN Mode
The RUN Mode must be selected for normal operation of the PSC3000, PSC4000 or
PSC5000 System. This section describes the selection method of the RUN Mode
and the keys that can be used in the RUN Mode.
4.2.1 Selection of the RUN Mode
To select the RUN Mode of the PSC Console, press the RUN key. The following
display will appear on the PSC Console.
When the PSC Console is powered up, the RUN Mode is automatically selected.
4.2.2 Keys That Can be Used in the RUN Mode
In the RUN Mode, only the keys grey-colored in Figure 4.1 can be used.
R U NSystem Line
