Remak VCS User Manual

103
Control units VCS
PLC Controller for Compressor Output Control
Code Description Range: Def.
S-00 Set Te -10.0…10.0°C 4.1
S-01 Set Tc 30.0…90.0°C 63.0
S-02 Set Cond 20.0…S-01°C 17.0
S-04 Full output Yes…No 15.0
P-01 PID LP_Udz --- 0
P-02 PID LP Ldz --- 0
P-03 PID LP BP --- 40.0
P-04 PID LP Ti --- 120.0
P-05 PID LP Td --- 0
P-06 PID LP Arw --- 1
P-07 PID LP Speed --- 0
P-10 Hyst UP 5…20 % 10
P-16 Set Td 90.0…140.0°C 120.0
P-17 Coolant type 0 – 9 5
P-20 Min T on 5…120 sec 30
P-21 Min T off 30…300 sec 60
P-22 PWM period 10…20 sec 10
P-23 Pen HP 3…10 3
P-24 Pei HP 15…60 min 15
P-25 Pen LP 3…10 3
P-26 Pei LP 15…60 min 15
P-32 PID HP_Udz --- 0
P-33 PID HP Ldz --- 0
P-34 PID HP BP --- 20.0
P-35 PID HP Ti --- 100.0
P-36 PID HP Td --- 0
P-37 PID HP Arw --- 1
P-38 PID HP Speed --- 0
P-40 BLP Bypass --- sec 30
P-41 BLP Filter --- sec 4
P-42 BLPA Bypass --- sec 60
P-43 BLPA Filter --- sec 120
P-45 Curb En --- Yes
P-47 Warning time 0…600 sec 60
P-48 Warning value 0…100 % 10
P-50 PID Cond BP --- 15.0
Standard Setting Values
P-51 PID Cond Ti --- 100.0
P-52 PID Cond Td --- 0
P-53 PID Cond _Utz --- 0
P-54 PID Cond Ldz --- 0
P-55 PID Cond Speed --- 0
P-56 PID Cond Arw --- 1
P-60 T inc 10…600 sec 60
P-61 T dec 0…120 sec 10
P-66 DP En --- No
P-67 Swap time --- sec 30
P-68 Def time --- sec 30
P-69 Def interval --- hod 6
P-70 Switch off --- Yes
P-71 Switch Cap 0…100 % 30
P-74 Defrost LP -10,0…2,5 °C 4,0
P-77 Maf --- 100
P-79 App --- -1
