Additional Display Views (P-79 parameter)
Code Description
Outr e sensor is out of the measuring range.
An06 Digital compressor discharge temperature.
An10 Evaporation temperature
An11 Condensation temperature
An12 Evaporation pressure
An13 Condensation pressure
An14 Inlet temperature 1
An15 Inlet temperature 2
AIL3 Input signal value (0 = 0V, 100 = 10V)
AIL4 LP sensor value (bar)
AIE4 HP sensor value (bar)
AOL3 Limiting value according to Te
AOE3 Limiting value according to Tc
AOE4 Condenser control analogue signal value
FrEE Electronics Menu active, only for service pur-
poses.
PLC Controller for Compressor Output Control
Packaging Self-extinguishing ABS plastic
Box
Front panel, 32 × 74 mm, depth 80 mm
Panel degree of protection
IP65
Connection
Screw terminal box for wires up to 2.5 mm2 cross-section
Supply voltage
12, 24 V AC
Input power
Max. 6 VA
Display
Four-digit, red LEDs, digit height 14.2 mm
Inlets
Up to 5 sensors NTC (-40 to 110°C)
Additional inputs
6x digital tension-free contact
Relay outputs
4x switching relay, 2A, 250 V AC
Triac outputs
1x triac relay, 2A, 250 V AC
Analogue outputs
1× conf., 2× 0–10V
Data memory
EEPROM
Operating temperature range
-10°C to 55°C
Storing temperature range
-20°C to 85°C
Relative humidity
10 to 90 % (non-condensing)
Measuring and control range
Depending on the sensor used
Accuracy (at ambient temperature 25 °C)
± 0,7 °C ±1 digit
Technical Data
