36
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
339 A 340 U Cooling end point (outdoor temperature) 30 -64 64 °C
341 A 342 U Maximum cooling compensation (speed) 0 -100 100 %
343 A 344 U Heating initial point (outdoor temperature) 5 -64 64 °C
345 A 346 U Heating end point (outdoor temperature) -20 -64 64 °C
347 A 348 U Maximum heating compensation (speed) 0 -100 100 %
349 U Current cooling speed compensation -100 100 %
350 U Current heating speed compensation -100 100 %
Room (outlet) temperature dependent fan speed compensation
351 A 351 A Compensation function setting
0 increase 0
1 decrease
352 U
Actual compensation
0 100 %
353 A 353 A Required room temperature 20 0 99 °C
Heating/cooling dependent fan speed compensation
354 A 354 A Heating temperature hysteresis 1 0 20 °C
355 A 355 A Cooling temperature hysteresis 1 0 20 °C
356 U Heating compensation display 0 100 %
357 U Cooling compensation display 0 100 %
Air quality dependent compensation (damper position/fan speed)
358 A 359 U Compensation function setting (according to the sensor characteristics) 0 Normal 0
1 Inverted
360 A 361 U Required (allowable) value of the CO2, VOC, (CO) concentration 800(50) 0 3000 ppm
362 A 363 U CO2, VOC, (CO) sensor range setting 2000(300) 0 3000 ppm
364 U CO2, VOC (CO) compensation rate display 0 100 %
Sequence
Heat pump - heating
365 A 366 U Outdoor temperature dependent heat pump blocking -8 -45 35 °C
367 A 368 U
Temp. hysteresis applied for outdoor temperature dependent heat pump
unblocking
3 1 10 °C
369 A 370 U Minimum operating time for heat pump heating 60 0 9999 s
371 A 372 U Re-heating blocking 120 5 600 s
373 A 374 U Heat pump switching on 20 0 100 %
375 A 376 U Digital output opening hysteresis 10 1 100 %
377 U Information - outdoor temperature dependent heat pump heating blocking 0 inactive
1 active
Heat pump - cooling
378 A 379 U Outdoor temperature dependent heat pump blocking 14 -45 35 °C
380 A 381 U
Tep. hysteresis applied for outdoor temperature dependent heat pump
unblocking
3 1 10 °C
382 A 383 U Minimum operating time for heat pump cooling 60 0 9999 s
384 A 385 U Re-cooling blocking 120 5 600 s
386 A 387 U Heat pump switching on 20 0 100 %
388 A 389 U Digital output opening hysteresis 10 1 100 %
390 A 391 U Heat pump low reference signal setting for A output 30 0 50 %
392 U Information - outdoor temperature dependent heat pump cooling blocking 0 inactive
1 active
Heat Pump - Special
260 S Inversion signal for Heat Pump – heating 0 Off
1 On
261 S Inversion signal for Heat Pump – cooling 0 Off
1 On
262 S Special signal 0-10V (Daikin) switchover 0 Off
1 On
263 S e difference between the demand and the real signal to determine St2 40 0 100 %
264 S Time needed to pass from 0 to 100% 120 0 500 s
265 S e signal voltage request of heating (Toshiba) 3.25 0 10 V
266 S e signal voltage request of cooling (Toshiba) 6.25 0 10 V
267 S e signal voltage request of STOP (Toshiba) 0 0 10 V
