38
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
Mixing
484 A 484 U Minimum fresh air value setting 20 0 100 %
484 A 484 U Minimum fresh air value setting – Comfort mode (pool unit) 20 0 100 %
485 A 485 A Minimum fresh air value setting – Economy mode (pool unit) 20 0 100 %
484 A 485 U Minimum fresh air flow rate setting 20 0 100 %
486 A 487 U Starting temperature for mixing damper wide-open position 15 -64 64 °C
488 A 489 U Starting time for mixing damper wide-open position 60 0 600 s
490 U Mixing damper control signal recurrence vale (normal/inverse) 100 0 100 %
Max. limit of fresh air function (ventilation unit)
563 A 564 U Max. limit of fresh air according to T outdoor 40 0 100 %
565 A 566 U T outdoor from which the Max. limit of fresh air is activated -10 -100 100 °C
567 U Information about the Max. limit of fresh air activation 0 Inactive
1 Active
491 A 492 U Required temperature for pre-heating -20 -50 10 °C
493 A 494 U Outdoor dependent electric pre-heating blocking -30 -50 10 °C
495 A 496 U Heating request dependent el. –pre-heating switch-on 20 0 100 %
497 A 498 U Hysteresis for electric pre-heater switch-off 10 0 100 %
Electric reheating
502 A 503 U Heating request dependent electric re-heating start-up for Stage 1 20 0 100 %
504 A 505 U Hysteresis for electric re-heating switch-off 10 1 100 %
506 A 507 U Fan stage dependent outlet limitation ST1 100 0 100 %
508 A 509 U Fan stage dependent outlet limitation ST2 100 0 100 %
510 A 511 U Fan stage dependent outlet limitation ST3 100 0 100 %
512 A 513 U Fan stage dependent outlet limitation ST4 100 0 100 %
514 A 515 U Fan stage dependent outlet limitation ST5 100 0 100 %
Heat recovery
516 A 517 U Freezing determination temperature exchanger 1 -64 64 °C
518 A 519 U Start temperature for maximum - HRE speed/volume open BP PE 15 -64 64 °C
520 A 521 U Start time for maximum - HRE speed/volume open BP PE 60 0 600 s
522 A 523 U Heat recovery request dependent HRE run enabling 38 0 100 %
524 A 525 U Hysteresis for HRE run stop 5 0 100 %
526 U Information - antifreeze protection start-up 0 inactive
1 active
Night turning
527 A 528 U Time to next turning 3 0 9999 h
529 A 530 U Active turning time 300 0 9999 s
Humidification
531 A 532 U
Relative set-point of relative humidity - Comfort 40 0 100 %r.H.
535 A 536 U
Relative set-point of humidity - Economy 30 0 100 %r.H.
541 A 542 U
Humidification blocking in summer 0 Ne 0
1 Ano
545 U Humidification output %
550 G
Calculated current humidification set-point in the cascade
Dehumidification
533 A 534 U
Dehumidification relative set-point - Comfort 60 0 100 %r.H.
537 A 538 U
Dehumidification relative set-point - Economy 70 0 100 %r.H.
533 A 534 U Dehumidification required relative value 60 0 100 %r.H.
537 A 538 U Dehumidification required absolute value 12 0 100 g/kg
539 A 540 U Maximum humidity required value 80 0 100 %r.H.
543 U Current humidity value
544 U Maximum humidity %
546 U Dehumidification output %
547 U Dew point °C
548 A 549 U Dew point deviation 1 -64 64 °C
551 G Calculated current dehumidification required value for cascade control %r.H.
Humidity-dependent fan speed compensation
552 A 553 U Humidity required value for compensation 50 0 100 %r.H.
554 A 555 U Fan speed compensation function 0 increase 0
