Remak VCS User Manual

40
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
List of Data Points (HMI-SG controller)
677 S 678 A Derivative factor - AP from return water 0 s
679 S 680 A Proportional factor - AP from inlet air 50
681 S 682 A Integrating factor - AP from inlet air 0 s
683 S 684 A Derivative factor - AP from inlet air 0 s
685 S 686 A Proportional factor - AP from max. return water temperature -3
687 S 688 A Integrating factor - AP from max. return water temperature 300 s
689 S 690 A Derivative factor - AP from max. return water temperature 0 s
691 S 692 A Proportional factor - from temperature request 5
693 S 694 A Integrating factor - from temperature request 150 s
695 S 696 A Derivative factor - from temperature request 0 s
Electric heating
697 S 698 A Proportional factor 2
699 S 701 A Integrating factor 60 s
702 S 703 A Derivative factor 0 s
Gas heating
704 S 705 A Proportional factor - burner 5
706 S 707 A Integrating factor - burner 60 s
708 S 709 A Derivative factor - burner 0 s
710 S 711 A Proportional factor - bypass damper -5
712 S 713 A Integrating factor - bypass damper 120 s
714 S 715 A Derivative factor - bypass damper 0 s
716 S 717 A Proportional factor - maximum temperature of flue gas 10
718 S 719 A Integrating factor - maximum temperature of flue gas 120 s
720 S 721 A Derivative factor - maximum temperature of flue gas 0 s
722 S 723 A Proportional factor - minimum temperature of flue gas -10
724 S 725 A Integrating factor - minimum temperature of flue gas 120 s
726 S 727 A Derivative factor - minimum temperature of flue gas 0 s
Cascade temperature control
728 S 729 A Proportional factor 10
730 S 731 A Integrating factor 1200 s
Cascade humidity control
732 S 733 A
Proportional factor 4
734 S 735 A
Integrating factor 0 s
Humidification
736 S 737 A
Proportional factor 5
738 S 739 A
Integrating factor 120 s
740 S 741 A
Derivative factor 0 s
732 S 733 A Proportional factor 4
734 S 735 A Integrating factor 0 s
Dehumidification
742 S 743 A Proportional factor -2
744 S 745 A Integrating factor 240 s
746 S 747 A Derivative factor 0 s
Humidity-dependent fan speed compensation
748 S 749 A Proportional factor -5
750 S 751 A Integrating factor 0 s
752 S 753 A Derivative factor 0 s
Constant Air Flow/Pressure Control - inlet
754 S 755 A Proportional factor 0.3
756 S 757 A Integration factor 30 s
758 S 759 A Differentiation factor 0 s
Constant Air Flow/Pressure Control - outlet
760 S 761 A Proportional factor 0.3
762 S 763 A Integration factor 30 s
764 S 765 A Differentiation factor 0 s
Checks, system and network settings
Humidity-dependent mixing damper position compensation
766 S 767 A Proportional factor -2
768 S 769 A Integrating factor 45 s
