42
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
843 S 843 S Number of message repeating during error transfers 2
844 S 844 S Number of error transfers for communication failure evaluation 6
845 S 845 S Frequency inverter 1 address, inlet fan 1
846 S 846 S Frequency inverter 2 address, inlet fan backup or second inlet fan 2
847 S 847 S Frequency inverter 3 address, inlet fan twin backup 3
848 S 848 S Frequency inverter 4 address, inlet fan twin backup 4
849 S 849 S Frequency inverter 5 address, outlet fan 5
850 S 850 S Frequency inverter 6 address, outlet fan backup or second outlet fan 6
851 S 851 S Frequency inverter 7 address, outlet fan twin backup 7
852 S 852 S Frequency inverter 8 address, outlet fan twin backup 8
853 S 853 S Frequency inverter 9 address, 3rd auxiliary fan 9
854 S 854 S Frequency inverter 10 address, second 3rd auxiliary fan 10
857 S 857 S Frequency inverter 11 address, rotary heat exchanger 11
858 S 858 S Control unit Modbus resistance terminal 0 inactive
1 active
Network connection configuration
(Aer setting – the reset is required !!)
859 A DHCP 0 passive
1 active
860 A Settings IP[w] 192 0 255
861 A Settings IP[x] 168 0 255
862 A Settings IP[y] 1 0 255
862 A Settings IP[z] 199 0 255
864 U Actual IP[w]
865 U Actual IP[x]
866 U Actual IP[y]
867 U Actual IP[z]
868 A Settings mask [w] 255 0 255
869 A Settings mask [x] 255 0 255
870 A Settings mask [y] 255 0 255
871 A Settings mask [z] 0 0 255
872 U Actual mask [w]
873 U Actual mask [x]
874 U Actual mask [y]
875 U Actual mask [z]
876 A Settings gateway [w] 0 0 255
877 A Settings gateway[x] 0 0 255
878 A Settings gateway [y] 0 0 255
879 A Settings gateway [z] 0 0 255
880 U Actual gateway [w]
881 U Actual gateway [x]
882 U Actual gateway [y]
883 U Actual gateway [z]
System settings - room unit
884 S 884 S Transition to time program delay 1 0 23 h
885 A 885 A Byte address, Diagnostic mode – byte address 5
886 A 886 A Alarm mode 0 N/A 2
1 only aer alarm
2 constantly
887 S 887 S Room temperature display, combined or inlet temperature 0 Temp. from HMI-SG 0
1 Temperature average
2 Outlet Temperature
3 Temperature in the inlet
895 U 895 U Temperature unit display settings °C/°F 0 °C 0
1 °F
896 A 896 A Required value compensation setting +/- 3 0 12 °C
897 A 897 A Required value increment 0 Increment per 0.1 0 °C
1 Increment per 0.5 °C
