List of Data Points (HMI-DM, HMI-TM and HMI@WEB controllers)
Menu HMI-DM,HMI-TM a HMI@WEB
Menu Meaning
Factory settings
Value Min Max
Units
MinRunTm Minimum operating time for heat pump heating 60 0 9999 s
BlckTmAgainStrt Re-heating blocking 120 5 600 s
ActiveHeatPump Heat pump switching on 20 0 100 %
HysOHeatPump Digital output opening hysteresis 10 1 100 %
AlarmFromOutTmp Information - outdoor temperature dependent heat pump heating blocking
StartAnalogVal Heat pump analogue signal lower level 30 0 50 %
HeatPump - cooling Heat pump - cooling
StptBlckOutTmp Outdoor temperature dependent heat pump blocking 14 -45 35 °C
StptHysOutTmp Temp. hysteresis for outdoor temperature dependent heat pump unblocking 3 1 10 °C
MinRunTm Minimum operating time for heat pump cooling 60 0 9999 s
BlckTmAgainStrt Re-cooling blocking 120 5 600 s
ActiveHeatPump Heat pump switching on 20 0 100 %
HysOHeatPump Digital output opening hysteresis 10 1 100 %
AlarmFromOutTmp Information - outdoor temperature dependent heat pump cooling blocking
StartAnalogVal Heat pump analogue signal lower level 30 0 50 %
HeatPump - special HeatPump - special
Invert signal heating Signal inversion - HeatPump heating mode
Invert signal cooling Signal inversion - HeatPump cooling mode
DaikinSpec0-10V 0-10V special signal switching (Daikin)
DierSt1-St2SigDaikin % dierence between request and St2 real signal 40 0 100 %
ChangeTimeToMaxSigDaikin Time needed for signal bypass 0–100% 120 0 500 s
StartAnalogVal Heat pump analogue signal lower level 30 0 50 %
Heat recovery Heat recovery
HeatExFreezAlarm Freezing determination heat exchanger 1 -64 64 °C
HeatExTmpMaxSpeed Start temperature for maximum - HRE speed/volume open BP PE 15 -64 64 °C
HeatExTmMaxSpeed Start time for maximum - HRE speed/volume open BP PE 60 0 600 s
SetStartRequestHeatEx Heat recovery request dependent HRE run enabling 38 0 100 %
SetHysHeatEx Hysteresis for HRE run stop 5 0 100 %
InfoStrtAntiFreez Information - antifreeze protection start-up
Mixing Mixing
MinFreshAir Minimum fresh air ow rate 20 0 100 %
MinFreshAir - Comfort Minimum fresh air ow rate - Comfort (pool unit) 20 0 100 %
MinFreshAir - Econom Minimum fresh air ow rate - Economy (pool unit) 20 0 100 %
MixDampTempFullOp Starting temperature for mixing damper wide-open position 15 -64 64 °C
MixDampTmFullOp Starting time for mixing damper wide-open position 60 0 600 s
ValueOfMixing Mixing damper control signal recurrence vale (normal/inverse) (%) 100 0 100 %
ActMaxFrshAirLim Information about the Max. limit of fresh air activation (vent. unit)
MaxFrshAir Max. limit of fresh air according to T outdoor (vent. unit)
ToutActMaxFrshAir T outdoor from which the Max. limit of fresh air is activated (vent. unit)
Cooling Cooling
ClgBlckOutTmp Outdoor temperature-dependent blocking 12 -64 64 °C
MinRumTmPump Minimum pump operating time 180 0 9999 s
PmpKickTm Pump downtime to the pump turning activation 168 0 9999 h
PmpKickTmOn Active pump turning time 60 0 9999 s
MinRunTm1StDXClg Minimum operating time; 1St condensing unit 60 0 9999 s
BlckTmAgainStrtDXCool Re-cooling blocking; 1St (2St) condensing unit 120 5 600 s
TmRemainIn1StDXCool Minimum dwell time in condensing unit's 1St; 2St condensing unit 360 5 600 s
DXCoolStage1On Condensing unit’s 1St switch-on 20 0 100 %
DXCoolStage2On Condensing unit’s 2St switch-on 70 0 100 %
DXCoolHysO1St Hysteresis for 1St - 2St transition, 2St condensing unit 10 0 20 %
MinRunTmInverter Minimum operating time; inverter 10 0 9999 s
BlckTmAgainDXCool+Inv Re-cooling blocking, 1St + condensing unit 60 0 300 s
Cooling signal inversion Signal Inversion for Heat Cooling Pump
OmezDleVlhkProst Cooling limited by room air humidity 65 0 100 %
Cooling 2
NastBlokOdVenkTep Outdoor temperature-dependent blocking of cooling 12 -64 64 °C
MinDobaProvČerpadla Minimum pump operating time 180 0 9999 s
Inverze signal chlazení Signal Inversion for Heat Cooling Pump
Cooling 3
NastBlokOdVenkTep Outdoor temperature-dependent blocking of cooling 12 -64 64 °C
MinDobaProvČerpadla Minimum pump operating time 180 0 9999 s
Cooling signal inversion Signal Inversion for Heat Pump Cooling
DemandHtg Heating Water Source Switching
StptTmpDemandHtg Heating-water heating start-up 15 5 25 °C
StptDlyStrtSeq Start-up sequence delay 120 10 600 s
CompensationRequestTemperatur Required temperature compensation
ClgCompStart Cooling initial point (outdoor temperature) 25 -64 64 °C
ClgCompEnd Cooling end point (outdoor temperature) 35 -64 64 °C
MaxValCompClg Maximum cooling compensation (required value) 2 -64 64 dK
ActShiftReqTempClg Required cooling value current shift -64 64 °C
CompHStart Heating initial point (outdoor temperature) 0 -64 64 °C
CompHEnd Heating end point (outdoor temperature) -20 -64 64 °C
MaxCompHtg Maximum heating compensation (required value) -1 -64 64 dK
ActShiftReqTempHtg Required heating value current shift -64 64 °C
FanCompensationOutTemperature Outdoor temperature-dependent fan speed compensation
ClgCompStart Cooling initial point (outdoor temperature) 25 -64 64 %
ClgCompEnd Cooling end point (outdoor temperature) 30 -64 64 °C
MaxValCompStgClg Maximum cooling compensation (speed) 0 -100 100 %
ActValComStgFanClg Current cooling speed compensation -100 100 %
CompHStart Heating initial point (outdoor temperature) 5 -64 64 °C
