Control units VCS
List of Data Points (HMI-DM, HMI-TM and HMI@WEB controllers)
Menu HMI-DM,HMI-TM a HMI@WEB
Menu Meaning
Factory settings
Value Min Max
Units
CompHEnd Heating end point (outdoor temperature) -20 -64 64 °C
MaxValCompStgHtg Maximum heating compensation (speed) 0 -100 100 %
ActValComStgFanHtg Current heating speed compensation -100 100 %
FanCompensationRoomExhaustTmp Room (Outlet) Temperature-Dependent Fan Speed Compensation
FunctionComp Compensation function setting
SpvTempInRoom Required room temperature 20 0 99 °C
ActValCom Actual compensation 0 100 %
FanCompensationSequenceHtg Heating dependent fan speed compensation
HysTempHeating Heating temperature hysteresis (°C) 1 0 20 °C
ActValCom Heating compensation display (%) 0 100 %
FanCompensationSequenceClg Cooling dependent fan speed compensation
HysTempCooling Cooling temperature hysteresis (°C) 1 0 20 °C
ActValCom Cooling compensation display (%) 0 100 %
Compensation air quality Air quality dependent compensation (damper position/fan speed)
SetFuncAirQuality Compensation function setting (according to the sensor characteristics)
SpvValueConcentration Required (allowable) value of the CO2, VOC, (CO) concentration 800(50) 0 3000 ppm
SettingRangeSensor CO2, VOC, (CO) sensor range setting 2000(300) 0 3000 ppm
ActValComp CO2, VOC (CO) compensation rate display, % 0 100 %
Humidity fan compensation Humidity-dependent fan speed compensation
FanCmpHumSpv Humidity required value for compensation 50 0 100 %r.H.
Func compensation Fan speed compensation function
ActValComp Compensation display %
Humidity Hrec Damp compensat Humidity-dependent mixing damper compensation
Func compensation Fan speed compensation function
ActValComp Compensation display %
TemperatureStart Temperature start-up
StrtTmpHeating Heating trigger temperature 25 -64 64 °C
SpvTmpHeating Required temperature for heating 25 -64 64 °C
StrtTmpCooling Cooling trigger temperature 30 -64 64 °C
SpvTmpCooling Required temperature for cooling 15 -64 64 °C
Temperature hysterese Hysteresis 1 0.1 64 °C
BlckTmAgainStart Heating and cooling blocking time 30 0 999 min
MinRunTm Minimum operating time 0 0 999 min
Night Cooling Night chilling
SpvTmpRoom Required room temperature, inlet-dependent control 22 -64 64 °C
HysTmpRoom Temperature hysteresis 3 0 64 °C
MinOutTmp Minimum outdoor temperature setting 12 -64 64 °C
OutRoomOnDiTmp Outdoor temperature and room temperature dierence 5 1 64 °C
MinRunTm Minimum operating time 30 0 999 min
Boost Optimized start
PreStrtTmTimeSchedul Pre-set interval before time program start-up 60 0 999 min
SpvTmpRoom Required room temperature - inlet-dependent control 20 -64 64 °C
HysTmp Temperature hysteresis 0.5 -64 64 °C
SpvTmpHeating Required temperature for heating 25 -64 64 °C
SpvTmpCooling Required cooling temperature 15 -64 64 °C
Night kick Night turning
DateTime Turning time
TmToNextKick Time to next turning (h) 3 0 9999 h
TmOn Active turning time (s) 300 0 9999 s
Control factors Control constants
TempCascade Cascade control factors
PropFactor Proportional factor 10
IntegFactor Integrating factor 1200 s
AntiFreezeRetWatHeat Return water AP factors
PropFactor Proportional factor 20
IntegFactor Integrating factor 90 s
DierFactor Derivative factor 0 s
AntiFreezeSplyTemp Inlet air AP factors
PropFactor Proportional factor 50
IntegFactor Integrating factor 0 s
DierFactor Derivative factor 0 s
MaxRetWatHeat Maximum return water temperature factors
PropFactor Proportional factor -3
IntegFactor Integrating factor 300 s
DierFactor Derivative factor 0 s
SetpointTempWaterHeating Water heating required temperature factors
PropFactor Proportional factor 5
IntegFactor Integrating factor 150 s
DierFactor Derivative factor 0 s
Electrical heating Electric heating factors
PropFactor Proportional factor 5
IntegFactor Integrating factor 120 s
DierFactor Derivative factor 0 s
BurnerFactors Gas burner factors
PropFactor Proportional factor 5
IntegFactor Integrating factor 60 s
DierFactor Derivative factor 0 s
Bypass damper Gas heater bypass damper factors
PropFactor Proportional factor -5
IntegFactor Integrating factor 120 s
DierFactor Derivative factor 0 s
