Remak VCS User Manual

82
Bit6 Heat pump DO 1
Bit7
Bit8 Extra el heating, off
Bit9 Extra el heating, stage 1
Bit10
Bit11
Bit12
Bit13 Request for humidification
Bit14
Bit15
3x0012
Digital outputs (Word 4)
0-65535
0-1 for each bit or counted binary
to a decimal number
Bit0
Bit1
Bit2 Burner heating, st1
Bit3 Burner heating, st2
Bit4 Burner heating, Mod+
Bit5 Burner heating, Mod-
Bit6
Bit7
Bit8 Alarm output, high
Bit9 Alarm output, low
Bit10
Bit11
Bit12
Bit13 Heating demand
Bit14 PreWtrHeating
Bit15 PreEl.Heating
Unsigned Word
3x0013
Alarms (Word 1)
0-65535
Bit0
Bit1
Bit2 Burner failure
Bit3 Supply fan
Bit4 Exhaust fan
Bit5 Fan operating hours
Bit6 Supply back up
Connection to the Master System (ModBus Standard)
Adress Description Values/Units Remarks
Input register (Read) (continuation)
