Remak VCS User Manual

85
Control units VCS
10=Stop
11=OverRun
12=StartUp
12=Start
3x0018 Act fan step 0-5 Off*Stage1*Stage2*St
age3*Stage4*Stage5
3x0019
3x0020 Op mode man st/tmp 0-11 Auto*Off*Eco St1*Comf
St1*Eco St2*Comf
St2*Eco St3*Comf
St3*Eco St4*Comf
St4*Eco St5*Comf St5
3x0021
3x0022 TSP steps/tmp 0-10 Off*Eco St1*Comf
St1*Eco St2*Comf
St2*Eco St3*Comf
St3*Eco St4*Comf
St4*Eco St5*Comf St5
3x0023 Act Opmode ext ctrl 0-6 Auto*Off*Stage
1*Stage 2*Stage
3*Stage 4*Stage 5
3x0024
3x0025 Supply (Exhaust) air damper cmd 0-1 Off*On
3x0026
3x0027
3x0028 Supply fan cmd 0-6 Off*Stage 1*Stage
2*Stage 3*Stage
4*Stage 5
3x0029 Sply fan outp sign 0-100%
3x0030 Exhaust fan cmd 0-6 Off*Stage 1*Stage
2*Stage 3*Stage
4*Stage 5
3x0031 Exh fan outp signal 0-100%
3x0032
3x0033 Cooling outp signal 0 - 100%
3x0034 Cooling pump cmd 0-1 Off*On
3x0035 Cooling DX cmd 0-2 Off*Stage 1*Stage 2
3x0036 Hrec outp signal 0 - 100%
3x0037
3x0038 Hrec dmpr outp sign 0 - 100%
3x0039 Inlet/outlet damper swimming pool unit 0 - 100%
3x0040 Heating outp signal 0 - 100%
Input register (Read) (continuation)
Connection to the Master System (ModBus Standard)
Adress Description Values/Units Remarks
