REMEHA Quinta Ace 160 - Service Manual

Questions and Answers

W
wolfetyroneSep 6, 2025
What should I do if the return temperature sensor is shorted or measures a high temperature on my REMEHA Quinta Ace 160?
- D
  Daniel CooperSep 6, 2025
  If the return temperature sensor is either shorted or measures a temperature above range in your REMEHA Boiler, it could be due to: * Return temperature sensor short-circuited: Bad connection: check the wiring and connectors. * Incorrectly fitted sensor: check that the sensor has been correctly fitted. * Faulty sensor: replace the sensor.
C
Charles MontgomeryAug 25, 2025
Why is the ionization current below the limit in my REMEHA Boiler?
- E
  Emily LewisAug 25, 2025
  If the measured ionization current is below the limit in your REMEHA Boiler, it could be due to several reasons: * No flame during operation: Vent the gas supply to remove air. * Gas valve issues: Ensure the gas valve is fully opened and check the gas supply pressure. * Air supply or flue gas blockage: Verify that the air supply inlet and flue gas outlet are not blocked. * Flue gas recirculation: Ensure there is no recirculation of flue gases.
S
Savannah GreenAug 25, 2025
Why has the flow temperature exceeded the maximum operating value in my REMEHA Quinta Ace 160 Boiler?
- J
  Jennifer HernandezAug 26, 2025
  If the flow temperature has exceeded the maximum operating value in your REMEHA Boiler, it could be due to: * A flow temperature sensor above normal range (high-limit thermostat): Check the wiring and connectors for bad connections. * No flow or insufficient flow: Check the circulation (direction, pump, valves), water pressure, and the cleanliness of the heat exchanger.
R
Rebecca AdamsSep 14, 2025
What does it mean when there is a Blocking Input of the Control Unit from device external environment on my REMEHA Quinta Ace 160 Boiler?
- A
  Angelica HintonSep 14, 2025
  If there is a Blocking Input of the Control Unit from device external environment in your REMEHA Boiler, it could be due to: * Blocking input is active: External cause: remove external cause. * Wrong parameter set: check the parameters.
D
David WhiteSep 23, 2025
What should I do if the second return temperature sensor is removed or measures a low temperature on my REMEHA Quinta Ace 160 Boiler?
- M
  Michael SandovalSep 23, 2025
  If the second return temperature sensor is either removed or measures a temperature below range in your REMEHA Boiler, it could be due to: * Second return temperature sensor open: Bad connection: check the wiring and connectors. * Incorrectly fitted sensor: check that the sensor has been correctly fitted. * Faulty sensor: replace the sensor.
R
Ruben CunninghamSep 10, 2025
What does it mean if a deviation in flue sensor 1 and flue sensor 2 is detected on my REMEHA Quinta Ace 160?
- L
  ljohnsonSep 10, 2025
  If a deviation in flue sensor 1 and flue sensor 2 is detected in your REMEHA Boiler, it could be due to: * Flue gas temperature sensor deviation: Bad connection: check the connection. * Faulty sensor: replace the sensor.
K
Kimberly CurrySep 1, 2025
What causes the maximum temperature difference between the heat exchanger and flow in my REMEHA Quinta Ace 160?
- S
  Sherry DuncanSep 2, 2025
  If there's a maximum difference between the heat exchanger temperature and flow temperature in your REMEHA Boiler, it could be due to: * No flow or insufficient flow: Check the circulation (direction, pump, valves), water pressure, the cleanliness of the heat exchanger, and ensure the installation has been correctly vented to remove air. * Sensor error: Check that the sensors are operating correctly and that the sensor has been fitted properly.
A
Angel WilliamsSep 2, 2025
Why is there a maximum temperature difference between the heat exchanger and return in my REMEHA Quinta Ace 160 Boiler?
- X
  xdavisSep 2, 2025
  If there's a maximum difference between the heat exchanger temperature and return temperature in your REMEHA Boiler, it could be due to: * No flow or insufficient flow: Check the circulation (direction, pump, valves), water pressure, the cleanliness of the heat exchanger, and ensure the installation has been correctly vented to remove air. * Sensor error: Check that the sensors are operating correctly and that the sensor has been fitted properly.
K
Kimberly BeardSep 18, 2025
What does it mean if the CSU does not match CU type on my REMEHA Quinta Ace 160?
- R
  Randall SmithSep 18, 2025
  If the CSU does not match CU type on your REMEHA Boiler, it indicates a configuration error. To resolve this, reset CN1 and CN2.
M
morrisjoshuaAug 28, 2025
What does it mean when the Gas Valve Control unit communication exceeds feedback time on my REMEHA Boiler?
- H
  Haley JensenAug 28, 2025
  If the Gas Valve Control unit communication has exceeded the feedback time in your REMEHA Boiler, it could be due to: * Communication error with the security kernel: Restart the boiler. * CU-GH PCB issue: Replace the CU-GH PCB.

Summary

Safety

General safety instructions

General safety instructions for installers and end-users concerning gas and flue gas.

Specific safety instructions

Additional safety guidelines and information relevant to the installation and use of the boiler.

About this manual

Symbols used

Explains various danger levels and symbols used throughout the manual for user safety.

Technical specifications

Technical data

Provides detailed technical specifications including heat output, gas/flue gas data, and electrical characteristics.

Dimensions and connections

Illustrates the physical dimensions and connection points of the boiler.

Before installation

Installation regulations

Regulations and warnings for installers concerning the boiler installation process.

Lifting instruction

Guidance on safe lifting procedures for the boiler, recommending the use of lifting aids.

Installation

Positioning the boiler

Instructions and warnings for correctly mounting the boiler to the wall.

Hydraulic connections

Steps for connecting the central heating circuit, expansion vessel, and condensate drain.

Electrical connections

Procedures for making electrical connections, including the control unit and connection box.

Commissioning

Commissioning procedure

Step-by-step guide for initial boiler setup and start-up program verification.

Gas settings

Instructions for adjusting gas type and checking/setting combustion parameters.

Operation

Use of the control panel

Explains how to use the control panel, including symbols and menu navigation.

Shutdown

Procedures for safely shutting down the boiler for extended periods.

Settings

Changing the parameters

Guide on navigating the installer menu and modifying boiler parameters.

List of parameters

Detailed list and description of various parameters for configuration and adjustment.

Maintenance

Standard inspection and maintenance operations

Routine checks and maintenance tasks to ensure proper boiler function.

Troubleshooting

Error codes

Explanation of different error code levels (Warning, Blocking, Lock-out) and their meanings.

Appendix

Checklist for commissioning

A checklist of tasks to be performed during the boiler's initial commissioning.

Checklist for annual maintenance

A checklist for performing annual inspection and servicing of the boiler.

REMEHA Quinta Ace 160 Specifications

General

Model	Quinta Ace 160
Category	Boiler
Output Power	160 kW
Max. Heat Output (80/60°C)	160 kW
Modulation Range	32 - 160 kW
Type	Condensing Boiler
Output	160 kW
Warranty	2 years
Fuel Type	Natural Gas
Fuel	Natural Gas
