Sièges enfant : fixation par système isofix (XFK - Renault)
The table below summarises the information already shown on the diagram on the following pages, to ensure the appli-
cable regulations are respected.
Van version with front passenger seat equipped with ISOFIX system
Type of child seat
Weight of
the child
Size of ISOFIX
seat [Size]
Front passenger seat
airbag activated on
passenger side
without passenger airbag
or with it deactivated
Carrycot fitted across the
vehicle
Group 0
< 10 kg L1 [F], L2 [G] X X
Rear-facing shell seat
Groups 0 or 0 +
< 13 kg R1 [E] X IL (1) (2)
Shell seat/
rear-facing
seat
Group 0 + < 13 kg R3 [C] X IL (1) (2)
Group 1 9 to 18 kg R2 [D], R2X [D] X IL (1) (2)
Forward-facing seat
Group 1
9 to 18 kg
F3 [A], F2 [B],
F2X [B1]
IUF - IL (1) X
Booster seat
Groups 2 and 3
15 to 25 kg
22 to 36 kg
B2, B3 IUF - IL (1) X
Seat i-Size i-UF (1) i-U (1) (2)
CHILD SEATS: fitted using the ISOFIX SYSTEM (1/15)
