Aérateurs (sorties air) (XFK - Renault)
Air Vents
AIR VENTS: air outlets (1/3)
6
5
1 Demister outlets for side windows
2 Side air vents
3 Windscreen demisting vents
4 Centre air vents
5
4
2
3
3
1
2
1
3
5 Footwell heater outlets for front passengers
6 Control panel
7 Footwell heater outlets for rear passengers
(depending on the vehicle)
8 Rear console air vents (depending on the ve-
hicle)
7
8
