Renault Kangoo - Rear Parcel Shelf

rear parcel shelf .........................................
(up to the end of the DU)
rear parcel shelf .........................................
(up to the end of the DU)
3.62
ENG_UD77688_1
Tablette arrière (XFK - Renault)
Rear parcel shelf
Do not place any heavy or
hard object on the parcel
shelf. These may pose a
risk to the vehicle occu-
pants if the driver has to brake sud-
denly or if the vehicle is involved in
an accident.
REAR PARCEL SHELF
The shelf is made up of two rigid sec-
tions.
There are two possible positions:
– top position A;
In this case, you can fold section 2 onto
section 1 by lifting it as shown by the
arrow.
A
– Storage position B.
To store the parcel shelf, slide it into the
runner 3 behind the rear bench seat-
back.
B
2
1
3
2
1
