Renault Kangoo - Luggage Cover

luggage compartment cover ......................
(up to the end of the DU)
3.63
ENG_UD81030_1
Cache-bagages (XFK - Renault)
Luggage cover
LUGGAGE COMPARTMENT COVER (1/2)
Pull the handle 3 gently to release the
pins 4 from their anchoring points 6
located on each side of the luggage
compartment, then roll up the luggage
cover 5.
Guide the luggage cover onto the
roller 5.
To roll out the flexible section of the
luggage cover, proceed in the reverse
order.
It is prohibited to fit the luggage
cover behind the second row seats
if there are passengers on the third
row seats.
5
A
1
2
To remove the flexible
section of the luggage cover
On equipped vehicles, it can be in-
stalled in two positions:
– behind the second row seats (po-
sition A). In this case, the third row
seats must either be in the table po-
sition, in the folded position or re-
moved from the vehicle.
– behind the third row seats (posi-
tion B).
Ensure that each strap 1 is securely
fixed in its tab 2.
3
5
4
B
6
