2.121
ENG_UD72820_1
Aide au parking (XFK - Renault)
Parking distance control
PARKING DISTANCE CONTROL (1/8)
Operating principle
Ultrasonic sensors fitted in the bumpers
measure the distance between the ve-
hicle and an obstacle.
This measurement is indicated by
beeps which become more frequent the
closer you come to the obstacle, until
they become a continuous beep when
the vehicle is approximately 30 centi-
metres from the obstacle.
Depending on the vehicle, the system
detects obstacles to the front, the rear
and the sides of the vehicle.
The parking distance control system
is only activated when the vehicle is
driven at a speed below approximately
6 mph (10 km/h).
The function does not take into account
towing or carrying systems that are not
recognised by the system.
Location of the ultrasonic
sensors 1
Ensure that the ultrasonic sensors indi-
cated by the arrows 1 are not obscured
(by dirt, mud, snow, a badly fitted/at-
tached number plate), impacted, mod-
ified (including paintwork) or obstructed
by any accessory fitted to the rear and/
or, depending on the vehicle, to the
front or sides of your vehicle.
This function is an addi-
tional aid that uses sound
signals to indicate the dis-
tance between the vehicle
and an obstacle during reversing.
Under no circumstances should it
replace the driver’s care or respon-
sibility whilst reversing.
The driver should always be ready
for sudden incidents while driv-
ing: always ensure that there are
no small, narrow moving obstacles
(such as a child, animal, pushchair,
bicycle, stone, post, etc.) in the blind
spot when manoeuvring.
