Renault Kangoo - Luggage Net

deflector
luggage net ..........................................
(up to the end of the DU)
3.65
ENG_UD81097_2
Filet de retenue de bagages (XFK - Renault)
On equipped vehicles, the luggage net
can be used, when transporting ani-
mals or luggage, to separate them from
the passenger section.
It is fitted behind the rear seats or
behind the driver and front passenger
seats.
Luggage net
LUGGAGE NET (1/4)
1
2
3
3
5
The luggage net is de-
signed to retain a maximum
weight of 10 kg.
Risk of injury.
A
The luggage net must not
be used to attach objects.
Risk of injury.
Fitting the luggage net
behind the rear seats
(standard chassis)
Inside the vehicle and on each side:
– Insert the top rod 4 of the net into the
anchorage points 3 (the opening of
the net A must be positioned on the
right-hand side of the vehicle);
– pass the lower straps 5 of the net
through the anchorage points 6;
– then insert them into the 7 net lock-
ing system;
– adjust the net strap 5 so that it is taut.
4
A
7
5
6
