bonnet........................................................
(up to the end of the DU)
4.2
ENG_UD72849_1
Capot moteur (XFK - Renault)
Bonnet
To open the bonnet, open a door and
pull the 1 handle, located on the left-
hand side of the dashboard.
BONNET (1/2)
Do not press down on the
bonnet: there is a risk that
the bonnet may accidentally
close.
When working in the engine
compartment, ensure that
the windscreen wiper stalk
is in the park position.
Risk of injury.
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition. ➥ 2.2
➥ 2.3.
1
Opening the bonnet
To unlock, gently lift the bonnet and
push tab 2 in the direction of arrow A to
release the bonnet.
Lift the bonnet, guiding it up, and it
will rest in position with the help of two
struts 3.
3
2
A
After any procedure in the
engine compartment, make
sure that you do not forget
anything (cloth, tools, etc.).
These may damage the engine or
cause a fire.
