Véhicule électrique : Présentation (XFK - Renault)
Electric vehicle: presentation, important recommendations, charging, programming
1 Electric charging connection
2 Electric motor
3 Secondary 12V battery
4 400 V traction battery
5 Orange “400 V” electrical power cables
ELECTRIC VEHICLE: introduction (1/6)
1
2
3
4
5
