Rangements / Aménagements habitacle (XFK - Renault)
12
Centre armrest storage
compartment 11
Lift the armrest cover 10.
Centre console storage
compartment 12
10
Cup holders 9
Depending on the vehicle, the cup
holder may be equipped with retaining
hooks to keep the cup in place.
This can be used to store a mobile ash-
tray, drink cans, etc.
When turning corners, accelerating or braking, ensure that the receptacle
being held by the cup holder is not dislodged.
There is a risk of injury if hot liquid escapes.
11
9
PASSENGER COMPARTMENT STORAGE, FITTINGS (3/8)
