Storage compartment 23
under front passenger seat
(for vehicles fitted with front bench seat
for two)
To get to it:
– pull the front of the bench seat cush-
ion C as far as the stop;
– then, lift the rear section B of the
cushion and pivot the seat base.
PASSENGER COMPARTMENT STORAGE, FITTINGS (6/8)
To replace the seat, proceed in reverse:
– lift the bench seat cushion so as to
position the rear section B of the
cushion under the seatback;
– push down on the front of the cush-
ion C so as to lock the seat base.
Check that the bonnet is correctly
locked.
23
C
B
When turning corners, accelerating or braking, ensure that the receptacle
being held by the cup holder is not dislodged.
There is a risk of injury if hot liquid escapes.
B
Maximum load weight allowed in the
storage area 23: 10 kg.
Parcel shelf 24, storage area 25, pen
holder 26 and cup holder 27
(depending on the vehicle)
Lower the seatback D ➥ 1.60.
Depending on the vehicle, the cup
holder may be equipped with retaining
hooks to keep the cup in place. This
can be used for storing a mobile ash-
tray, cup holder, etc.
27
24
25
26
D
