Appuis-tête arrière (XFK - Renault)
REAR HEADRESTS (2/3)
Long chassis version
(5-seater or 7-seater)
Position for use
Lift the headrest fully until it locks.
Check that the bonnet is correctly
locked.
To remove the headrest
Raise the headrest as far as it will go,
then press button 3 or 4 and remove
the headrest.
3
4
To replace it
Fit the rods into their housing and push
down the headrest until it locks to set it
to raised position.
Check that the bonnet is correctly
locked.
The headrest is a safety
component; check that it is
fitted and in the correct po-
sition.
