Siège arrière: version châssis long (XFK - Renault)
REAR SEATS : long chassis version (13/18)
To reposition the seat
– Pull the red strap 14 as far as it will
go and lower the seat (movement H)
until it locks onto the floor;
– Make sure the seat is correctly
locked in position;
– Lift the seatback (movement F) by
pushing the handle 13.
No person or animal should
be on the third row rear
seats if the luggage com-
partment cover is not re-
moved.
When moving the rear
seats, ensure that nothing
obstructs the anchorage
points (passenger’s arm or
leg, a pet, gravel, cloth, toys, etc.).
When moving third row rear
seats:
– Check that nobody is near
any of the moving parts;
– Check that there is sufficient
space around the seat;
– Check that nothing is obstructing
the section of the boot reserved
for storing the seat.
For safety reasons, carry out any
adjustments when the vehicle is sta-
tionary.
H
F
14
13
