Siège arrière: version châssis long (XFK - Renault)
REAR SEATS : long chassis version (17/18)
To install seats
(continued)
To connect the connector 17:
– Remove the flap 20;
– Unhook the cable 21 from the con-
nector on the clip 22;
When refitting a seat in the vehicle,
be sure to reconnect the seat con-
nector. If this is not the case, the
seat belt buckle information will not
be shown on the instrument panel
➥ 1.69.
– Plug in the connector 17 and lock the
red tab 19;
– Reposition the cable 21 in the carpet
recess 28;
– Replace the flap 20.
17
22
21
20
17
19
20
28
21
