CLIMATE CONTROL (continued)
Distribution of air in the
passenger compartment
Therearefivepossible
combinations for air distribution,
which may be selected by pressing
buttons 8 and 10 repeatedly. The
arrows on display 5 indicate the
setting selected:
Position
All the air flow is directed to the
demisting vents for the windscreen
and the side windows.
Position
The air flow is directed to the
windscreen demisting vents, the
side windows and the passenger
footwell.
Position
The air flow is mainly directed
towards all the air vents.
Position
The air flow is directed to all the air
vents and the passenger footwells.
Position
The air flow is only directed to the
passenger footwells.
The manual air distribution
option causes the operating
warning light on the display 5 to
go out (automatic mode), but
only air distribution is no longer
controlled automatically by the
system.
Press button 6 to return to
automatic mode.
