CHILD SEATS
2
Getting to know your vehicle - 105
B3 = Seat enabling a child seat with "B3" approval to be attached by seat belt: check that it can be fitted.
(2)Acarrycotcanbeinstalledacrossthevehicleanditwilltakeupatleasttwoseats.Positionthechildwithhisorherfeetnear-
est the door.
(3)Ifnecessary,positionthevehicleseatasfarbackaspossibleandraisetheseatback(byapproximately25°).Inordertoin-
stall a rear-facing child seat, move the front seat as far forward as possible, then move the front seat back as far as it will go,
without allowing it to come into contact with the child seat.
( 4 ) In all situations, remove the headrest of the rear seat on which the child seat is positioned. This must be done before fitting
the child seat. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat and the
child's legs.
(5) Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
(6) Deactivate the "Easy Access Seat" function before installing a child seat on the front passenger seat and/or on
the rear seats.
Risk of injury.
