CHILD SEATS
2
Getting to know your vehicle - 109
Installation table
The table below summarises the information shown on the following diagram in order to ensure the regulations in
force are respected.
Type of child seat
Weight of the
child
Size of seat
[fixture]
Front passenger seat (7)
Rear side
seats (7)
Rear centre
seat (7)
With airbag
deactivated
With airbag
activated
Carrycot fitted across
the vehicle
Group 0
< 10 kg
L1 [F]
L2 [G]
X X IL (2) X
Rear-facing shell seat
Groups 0 or 0 +
< 13 kg R1 [E] IL (1) (3) X IL (4) X
Rear-facing seat
Groups 0+ and 1
< to 13 kg and
9 to 18 kg
R3 [C]
R2 [D]
IL (1) (3) X IL (4) X
Forward-facing seat
Group 1
9 to 18 kg
F3 [A]
F2 [B]
F2X [B1]
X
IUF - IL
(3)
IUF - IL
(5)
X
Booster seat
Groups 2 and 3
15 to 25 kg B2 X IUF - IL (6) IUF - IL (5) X
22 to 36 kg B3 X IUF - IL (6) IUF - IL (5) X
Seati-Size
Rear-facing seat i - U (1) (3) X i - U (4) X
Forward-facing seat X i - UF (3) i - U (5) X
Booster seat X i - UF (6) i - U (5) X
X = Seat not suitable for fitting child seats of this type.
IUF = Seat allowing a child seat with "Universal or vehicle-specific" approval to be attached using the ISOFIX system on
equipped vehicles; check that it can be fitted.
