E-TECH PLUG-IN HYBRID VEHICLE (PHEV)
2
40 - Getting to know your vehicle
Charging cords
Charging lead A
(14/16 amps)
(10 amps)
Depending on the vehicle, either the
10 A or 16 A cable can be used for:
– in normal use, on a socket used only
for the vehicle (14 A/16 A charging);
– occasionalchargingusingadomes-
tic socket (8 A charging) when you are
not at home, for example.
In all cases, sockets must be fitted as
stated in the instructions provided with
the charging cable A .
In all cases, carefullyreadthecharg-
ingcableusermanual A .
Never leave the socket
hanging by the cord. Use
the hooks C to hang it.
Ifamalfunctionoccursdur-
ing the charging process
(red warning light appears
on the unit D ),stopchargingim-
mediately.Pleaserefertocordin-
structions.
