Renesas RH850/U2A 144pin

RH850/U2A 144pin 7. Connectors
R20UT5089ED0101 Rev.1.01 Page 24 of 56
July 08, 2022
Table 7.2 Main board connector CN2 (cont'd)
Pin Function Device port Pin Function Device port
29 LIN12TX ‒ 30 LIN13TX ‒
31 LIN12RX ‒ 32 LIN13RX ‒
33 LIN14TX ‒ 34 LIN15TX ‒
35 LIN14RX ‒ 36 LIN15RX ‒
37 ‒ ‒ 38 ‒ ‒
39 CAN12TX ‒ 40 CAN13TX ‒
41 CAN12RX ‒ 42 CAN13RX ‒
43 CAN14TX ‒ 44 CAN15TX ‒
45 CAN14RX ‒ 46 CAN15RX ‒
47 CAN6TX P4_14 48 CAN7TX ‒
49 CAN6RX P4_15 50 CAN7RX ‒
51 CAN8TX ‒ 52 CAN9TX ‒
53 CAN8RX ‒ 54 CAN9RX ‒
55 CAN10TX ‒ 56 CAN11TX ‒
57 CAN10RX ‒ 58 CAN11RX ‒
59 ‒ ‒ 60 ‒ ‒
61 LIN16TX ‒ 62 LIN17TX ‒
63 LIN16RX ‒ 64 LIN17RX ‒
65 LIN18TX ‒ 66 LIN19TX ‒
67 LIN18RX ‒ 68 LIN19RX ‒
69 LIN20TX ‒ 70 LIN21TX ‒
71 LIN20RX ‒ 72 LIN21RX ‒
73 LIN22TX ‒ 74 LIN23TX ‒
75 LIN22RX ‒ 76 LIN23RX ‒
77 ‒ ‒ 78 ‒ ‒
79 SFMA0CLK ‒ 80 SFMA0SSL ‒
81 SFMA0IO0 ‒ 82 SFMA0IO1 ‒
83 SFMA0IO2 ‒ 84 SFMA0IO3 ‒
85 ‒ ‒ 86 ‒ ‒
87 MMCA0CLK ‒ 88 MMCA0CMD ‒
89 MMCA0DAT0 ‒ 90 MMCA0DAT1 ‒
