6. Other Circuitry
6.1 Operation Mode Selection
The piggyback board gives the possibility to configure the following jumpers for selection of
the device operation mode:
Table 6.1 Device operation mode selection jumpers (cont'd)
Jumper Function
JP38 MODE0 pin level
• JP38[2-1]: MODE0 = H level
• JP38[2-3]: MODE0 = GND
JP41 FLMD0 pin level
• JP41[SHORT]: FLMD0 = H level
• JP41[OPEN]: FLMD0
− controlled by debugger or programming tool if a tool is connected via CN4
− GND, if no tool connected
JP39 FLMD1 pin level
• JP39[SHORT]: FLMD1 = H level
• JP39[OPEN]: FLMD1 = GND
JP40 FLMD2 pin level
• JP40[2-1]: FLMD2 = H level
• JP40[2-3]: FLMD2 = GND
