Renesas RH850/U2A 144pin

RH850/U2A 144pin 7. Connectors
R20UT5089ED0101 Rev.1.01 Page 25 of 56
July 08, 2022
Table 7.2 Main board connector CN2 (cont'd)
Pin Function Device port Pin Function Device port
91 MMCA0DAT2 ‒ 92 MMCA0DAT3 ‒
93 MMCA0DAT4 ‒ 94 MMCA0DAT5 ‒
95 MMCA0DAT6 ‒ 96 MMCA0DAT7 ‒
97 ‒ ‒ 98 ‒ ‒
99 ETH1MDIO ‒ 100 ETH1MDC ‒
101 ETH1RXD0 ‒ 102 ETH1TXD0 ‒
103 ETH1RXD1 ‒ 104 ETH1TXD1 ‒
105 ETH1RXD2 ‒ 106 ETH1TXD2 ‒
107 ETH1RXD3 ‒ 108 ETH1TXD3 ‒
109 ETH1RXCLK ‒ 110 ETH1TXCLK ‒
111 ETH1RXER ‒ 112 ETH1TXER ‒
113 ETH1CRSDV ‒ 114 ETH1TXEN ‒
115 ETH1RXDV ‒ 116 ETH1COL ‒
117 ETH1RESET ‒ 118 ETH1LINK ‒
119 ‒ ‒ 120 ‒ ‒
121 GND ‒ 122 GND ‒
123 GND ‒ 124 GND ‒
125 GND ‒ 126 GND ‒
127 GND ‒ 128 GND ‒
7.1.3 Main Board Connector CN3
Table 7.3 Main board connector CN3 (cont'd)
Pin Function Device port Pin Function Device port
1 CSI0CS0 P2_14 2 CSI0CLK P2_12
3 CSI0CS1 P10_14 4 CSI0SI P2_11
5 CSI0CS2 P4_13 6 CSI0SO P2_13
7 CSI0CS3 P6_11 8 ‒ ‒
9 ‒ ‒ 10 CSI1CS1 P24_8
11 ‒ ‒ 12 ‒ ‒
13 PSI5SRX1 P6_13 14 PSI5RX1 P5_2
15 PSI5STX1 P6_14 16 PSI5TX1 P5_3
