RH850/U2A 144pin 7. Connectors
R20UT5089ED0101 Rev.1.01 Page 29 of 56
July 08, 2022
7.4 Device Ports Connectors CN13 to CN16
The device port connectors enable easy connection to almost all ports of the device.
CAUTION
The pin headers are directly connected to the pins, therefore special care must be taken to avoid any
electrostatic or other damage to the device.
7.4.1 Device Ports Connector CN13
Table 7.6 Device port connector CN13
Pin Device port Pin Device port
37 A0VREFH 38 A0VSS
39 AP0_0 40 AP0_1
41 AP0_2 42 AP0_3
43 AP0_4 44 AP0_5
45 AP0_6 46 AP0_7
47 AP0_8 48 AP0_9
49 VDD 50 P3_2
51 P3_3 52 P4_0
53 VDD 54 P24_7
55 P24_8 56 E2VCC
57 P4_5 58 P4_6
59 P4_7 60 P24_11
61 P4_8 62 VDD
63 P4_9 64 P4_10
65 E0VCC 66 VDD
67 P4_13 68 P4_14
69 P4_15 70 P3_4
71 P3_5 72 P6_11
