RH850/U2A 144pin 7. Connectors
R20UT5089ED0101 Rev.1.01 Page 31 of 56
July 08, 2022
7.4.3 Device Ports Connector CN15
Table 7.8 Device ports connector CN15
Pin Device port Pin Device port
73 GND 74 A2VREFH
75 P6_4 76 P6_5
77 P6_6 78 VDD
79 P6_8 80 P6_9
81 P6_12 82 P3_6
83 P3_7 84 E0VCC
85 P6_10 86 VDD
87 P6_15 88 P6_13
89 P6_14 90 JP0_5
91 JP0_3 92 JP0_2
93 JP0_1 94 JP0_0
95 TRSTZ 96 RESETZ
97 FLMD0 98 VDD
99 X2_C * 100 VSS
101 X1_C * 102 SYSVCC
103 AWOVCL 104 PWRCTL
105 VMONOUTZ 106 P5_2
107 E0VCC 108 P5_4
Note * By default these signals are not connected to CN15 in order to minimize signal interference. If required they
can be connected via 0 Ω resistors R3 and R4.
