7.4.4 Device Ports Connector CN16
Table 7.9 Device ports connector CN16
Pin Device port Pin Device port
109 P5_3 110 VDD
111 P5_6 112 P2_2
113 P2_0 114 SVRAVCC
115 SVRAVSS 116 SVRDRVSS
117 DCDC_N 118 DCDC_P
119 SVRDRVCC 120 P2_11
121 E0VCC 122 P2_13
123 P2_14 124 P2_12
125 VDD 126 P2_15
127 VDD 128 P20_1
129 P20_2 130 P20_3
131 P20_4 132 P20_5
133 P20_10 134 P20_7
135 P20_6 136 VDD
137 P20_8 138 P20_9
139 P20_10 140 P20_12
141 P20_13 142 VCC
143 VSS 144 ERROROUTZ
