Revision History
Rev. Date
Description
Page Summary
V1.01 2022-07-08 ‒
Corrected jumper JP41 setting in Figure 8.1 Stand-alone operation
with single external power supply 3.3V, Figure 8.2 Stand-alone
operation with single external power supply 5.0V, Figure 8.3 Stand-
alone operation with maximum external power supply and Figure 8.4
Main board operation without external power supply
Corrected the description for power supply connectors CN8 – CN11 in
chapter 8.2.6 Operation on the Main Board: No External Supply
V1.00 2022-03-31 ‒ Initial release
