Renesas RL78/G1D User Manual

RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1038
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
LVD Detection Voltage of Interrupt & Reset Mode
(T
A = −40 to +85°C, VPDR ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
VLVD13 VPOC0, VPOC1, VPOC2 = 0, 0, 0, falling reset voltage: 1.6 V
1.60 1.63 1.66 V
Rising release reset voltage
1.74 1.77 1.81 V
VLVD12
LVIS0, LVIS1 = 1, 0
(+0.1 V)
Falling interrupt voltage
1.70 1.73 1.77 V
Rising release reset voltage
1.84 1.88 1.91 V
VLVD11
LVIS0, LVIS1 = 0, 1
(+0.2 V)
Falling interrupt voltage
1.80 1.84 1.87 V
Rising release reset voltage
2.86 2.92 2.97 V
VLVD4
LVIS0, LVIS1 = 0, 0
(+1.2 V)
Falling interrupt voltage
2.80 2.86 2.91 V
VLVD11 VPOC0, VPOC1, VPOC2 = 0, 0, 1, falling reset voltage: 1.8 V
1.80 1.84 1.87 V
Rising release reset voltage
1.94 1.98 2.02 V
VLVD10
LVIS0, LVIS1 = 1, 0
(+0.1 V)
Falling interrupt voltage
1.90 1.94 1.98 V
Rising release reset voltage
2.05 2.09 2.13 V
VLVD9
LVIS0, LVIS1 = 0, 1
(+0.2 V)
Falling interrupt voltage
2.00 2.04 2.08 V
Rising release reset voltage
3.07 3.13 3.19 V
VLVD2
LVIS0, LVIS1 = 0, 0
(+1.2 V)
Falling interrupt voltage
3.00 3.06 3.12 V
VLVD8 VPOC0, VPOC1, VPOC2 = 0, 1, 0, falling reset voltage: 2.4 V
2.40 2.45 2.50 V
Rising release reset voltage
2.56 2.61 2.66 V
VLVD7
LVIS0, LVIS1 = 1, 0
(+0.1 V)
Falling interrupt voltage
2.50 2.55 2.60 V
Rising release reset voltage
2.66 2.71 2.76 V
VLVD6
LVIS0, LVIS1 = 0, 1
(+0.2 V)
Falling interrupt voltage
2.60 2.65 2.70 V
Rising release reset voltage
3.68 3.75 3.82 V
VLVD1
LVIS0, LVIS1 = 0, 0
(+1.2 V)
Falling interrupt voltage
3.60 3.67 3.74 V
VLVD5 VPOC0, VPOC1, VPOC2 = 0, 1, 1, falling reset voltage: 2.7 V
2.70 2.75 2.81 V
Rising release reset voltage
2.86 2.92 2.97 V
VLVD4
LVIS0, LVIS1 = 1, 0
(+0.1 V)
Falling interrupt voltage
2.80 2.86 2.91 V
Rising release reset voltage
2.96 3.02 3.08 V
VLVD3
LVIS0, LVIS1 = 0, 1
(+0.2 V)
Falling interrupt voltage
2.90 2.96 3.02 V
Rising release reset voltage
3.98 4.06 4.14 V
Interrupt and reset
mode
V
LVD0
LVIS0, LVIS1 = 0, 0
(+1.2 V)
Falling interrupt voltage
3.90 3.98 4.06 V
