RL78/G13 CHAPTER 2 PIN FUNCTIONS
R01UH0146EJ0100 Rev.1.00 94
Sep 22, 2011
Table 2-3. Connection of Unused Pins (128-pin products) (3/4)
Pin Name I/O Circuit Type I/O Recommended Connection of Unused Pins
P70/KR0/SCK21/SCL21
P71/KR1/SI21/SDA21
P72/KR2/SO21
P73/KR3
P74/KR4/INTP8
P75/KR5/INTP9
P76/KR6/INTP10/(RxD2)
P77/KR7/INTP11/(TxD2)
8-R
P80/(SCK10)/(SCL10)
P81/(SI10)/(RxD1)/
(SDA10)
5-AN
P82/(SO10)/(TxD1)
P83
P84/(INTP6)
P85/(INTP7)
P86/(INTP8)
P87/(INTP9)
8-R
P90
P91
P92
P93
P94
P95/SCK11/SCL11
P96/SI11/SDA11
P97/SO11
8-R
P100/ANI20 11-U
P101
P102/TI06/TO06
P103/TI14/TO14
P104/TI15/TO15
P105/TI16/TO16
P106/TI17/TO17
P110/(INTP10)
P111/(INTP11)
P112
P113
P114
8-R
I/O
Input: Independently connect to EV
DD0, EVDD1 or EVSS0, EVSS1
via a resistor.
Output: Leave open.
Remarks 1. With products not provided with an EVDD0, EVDD1, EVSS0, or EVSS1 pin, replace EVDD0 and EVDD1 with VDD, or
replace EV
SS0 and EVSS1 with VSS.
2. Functions in parentheses in the above figure can be assigned via settings in the peripheral I/O redirection
register (PIOR).
