RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 112
Sep 22, 2011
Table 3-1. Correspondence Between Address Values and Block Numbers in Flash Memory (3/4)
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
40000H to 403FFH 100H 48000H to 483FFH 120H 50000H to 503FFH 140H 58000H to 583FFH 160H
40400H to 407FFH 101H 48400H to 487FFH 121H 50400H to 507FFH 141H 58400H to 587FFH 161H
40800H to 40BFFH 102H 48800H to 48BFFH 122H 50800H to 50BFFH 142H 58800H to 58BFFH 162H
40C00H to 40FFFH 103H 48C00H to 48FFFH 123H 50C00H to 50FFFH 143H 58C00H to 58FFFH 163H
41000H to 413FFH 104H 49000H to 493FFH 124H 51000H to 513FFH 144H 59000H to 593FFH 164H
41400H to 417FFH 105H 49400H to 497FFH 125H 51400H to 517FFH 145H 59400H to 597FFH 165H
41800H to 41BFFH 106H 49800H to 49BFFH 126H 51800H to 51BFFH 146H 59800H to 59BFFH 166H
41C00H to 41FFFH 107H 49C00H to 49FFFH 127H 51C00H to 51FFFH 147H 59C00H to 59FFFH 167H
42000H to 423FFH 108H 4A000H to 4A3FFH 128H 52000H to 523FFH 148H 5A000H to 5A3FFH 168H
42400H to 427FFH 109H 4A400H to 4A7FFH 129H 52400H to 527FFH 149H 5A400H to 5A7FFH 169H
42800H to 42BFFH 10AH 4A800H to 4ABFFH 12AH 52800H to 52BFFH 14AH 5A800H to 5ABFFH 16AH
42C00H to 42FFFH 10BH 4AC00H to 4AFFFH 12BH 52C00H to 52FFFH 14BH 5AC00H to 5AFFFH 16BH
43000H to 433FFH 10CH 4B000H to 4B3FFH 12CH 53000H to 533FFH 14CH 5B000H to 5B3FFH 16CH
43400H to 437FFH 10DH 4B400H to 4B7FFH 12DH 53400H to 537FFH 14DH 5B400H to 5B7FFH 16DH
43800H to 43BFFH 10EH 4B800H to 4BBFFH 12EH 53800H to 53BFFH 14EH 5B800H to 5BBFFH 16EH
43C00H to 43FFFH 10FH 4BC00H to 4BFFFH 12FH 53C00H to 53FFFH 14FH 5BC00H to 5BFFFH 16FH
44000H to 443FFH 110H 4C000H to 4C3FFH 130H 54000H to 543FFH 150H 5C000H to 5C3FFH 170H
44400H to 447FFH 111H 4C400H to 4C7FFH 131H 54400H to 547FFH 151H 5C400H to 5C7FFH 171H
44800H to 44BFFH 112H 4C800H to 4CBFFH 132H 54800H to 54BFFH 152H 5C800H to 5CBFFH 172H
44C00H to 44FFFH 113H 4CC00H to 4CFFFH 133H 54C00H to 54FFFH 153H 5CC00H to 5CFFFH 173H
45000H to 453FFH 114H 4D000H to 4D3FFH 134H 55000H to 553FFH 154H 5D000H to 5D3FFH 174H
45400H to 457FFH 115H 4D400H to 4D7FFH 135H 55400H to 557FFH 155H 5D400H to 5D7FFH 175H
45800H to 45BFFH 116H 4D800H to 4DBFFH 136H 55800H to 55BFFH 156H 5D800H to 5DBFFH 176H
45C00H to 45FFFH 117H 4DC00H to 4DFFFH 137H 55C00H to 55FFFH 157H 5DC00H to 5DFFFH 177H
46000H to 463FFH 118H 4E000H to 4E3FFH 138H 56000H to 563FFH 158H 5E000H to 5E3FFH 178H
46400H to 467FFH 119H 4E400H to 4E7FFH 139H 56400H to 567FFH 159H 5E400H to 5E7FFH 179H
46800H to 46BFFH 11AH 4E800H to 4EBFFH 13AH 56800H to 56BFFH 15AH 5E800H to 5EBFFH 17AH
46C00H to 46FFFH 11BH 4EC00H to 4EFFFH 13BH 56C00H to 56FFFH 15BH 5EC00H to 5EFFFH 17BH
47000H to 473FFH 11CH 4F000H to 4F3FFH 13CH 57000H to 573FFH 15CH 5F000H to 5F3FFH 17CH
47400H to 477FFH 11DH 4F400H to 4F7FFH 13DH 57400H to 577FFH 15DH 5F400H to 5F7FFH 17DH
47800H to 47BFFH 11EH 4F800H to 4FBFFH 13EH 57800H to 57BFFH 15EH 5F800H to 5FBFFH 17EH
47C00H to 47FFFH 11FH 4FC00H to 4FFFFH 13FH 57C00H to 57FFFH 15FH 5FC00H to 5FFFFH 17FH
