RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 113
Sep 22, 2011
Table 3-1. Correspondence Between Address Values and Block Numbers in Flash Memory (4/4)
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
60000H to 603FFH 180H 68000H to 683FFH 1A0H 70000H to 703FFH 1C0H 78000H to 783FFH 1E0H
60400H to 607FFH 181H 68400H to 687FFH 1A1H 70400H to 707FFH 1C1H 78400H to 787FFH 1E1H
60800H to 60BFFH 182H 68800H to 68BFFH 1A2H 70800H to 70BFFH 1C2H 78800H to 78BFFH 1E2H
60C00H to 60FFFH 183H 68C00H to 68FFFH 1A3H 70C00H to 70FFFH 1C3H 78C00H to 78FFFH 1E3H
61000H to 613FFH 184H 69000H to 693FFH 1A4H 71000H to 713FFH 1C4H 79000H to 793FFH 1E4H
61400H to 617FFH 185H 69400H to 697FFH 1A5H 71400H to 717FFH 1C5H 79400H to 797FFH 1E5H
61800H to 61BFFH 186H 69800H to 69BFFH 1A6H 71800H to 71BFFH 1C6H 79800H to 79BFFH 1E6H
61C00H to 61FFFH 187H 69C00H to 69FFFH 1A7H 71C00H to 71FFFH 1C7H 79C00H to 79FFFH 1E7H
62000H to 623FFH 188H 6A000H to 6A3FFH 1A8H 72000H to 723FFH 1C8H 7A000H to 7A3FFH 1E8H
62400H to 627FFH 189H 6A400H to 6A7FFH 1A9H 72400H to 727FFH 1C9H 7A400H to 7A7FFH 1E9H
62800H to 62BFFH 18AH 6A800H to 6ABFFH 1AAH 72800H to 72BFFH 1CAH 7A800H to 7ABFFH 1EAH
62C00H to 62FFFH 18BH 6AC00H to 6AFFFH 1ABH 72C00H to 72FFFH 1CBH 7AC00H to 7AFFFH 1EBH
63000H to 633FFH 18CH 6B000H to 6B3FFH 1ACH 73000H to 733FFH 1CCH 7B000H to 7B3FFH 1ECH
63400H to 637FFH 18DH 6B400H to 6B7FFH 1ADH 73400H to 737FFH 1CDH 7B400H to 7B7FFH 1EDH
63800H to 63BFFH 18EH 6B800H to 6BBFFH 1AEH 73800H to 73BFFH 1CEH 7B800H to 7BBFFH 1EEH
63C00H to 63FFFH 18FH 6BC00H to 6BFFFH 1AFH 73C00H to 73FFFH 1CFH 7BC00H to 7BFFFH 1EFH
64000H to 643FFH 190H 6C000H to 6C3FFH 1B0H 74000H to 743FFH 1D0H 7C000H to 7C3FFH 1F0H
64400H to 647FFH 191H 6C400H to 6C7FFH 1B1H 74400H to 747FFH 1D1H 7C400H to 7C7FFH 1F1H
64800H to 64BFFH 192H 6C800H to 6CBFFH 1B2H 74800H to 74BFFH 1D2H 7C800H to 7CBFFH 1F2H
64C00H to 64FFFH 193H 6CC00H to 6CFFFH 1B3H 74C00H to 74FFFH 1D3H 7CC00H to 7CFFFH 1F3H
65000H to 653FFH 194H 6D000H to 6D3FFH 1B4H 75000H to 753FFH 1D4H 7D000H to 7D3FFH 1F4H
65400H to 657FFH 195H 6D400H to 6D7FFH 1B5H 75400H to 757FFH 1D5H 7D400H to 7D7FFH 1F5H
65800H to 65BFFH 196H 6D800H to 6DBFFH 1B6H 75800H to 75BFFH 1D6H 7D800H to 7DBFFH 1F6H
65C00H to 65FFFH 197H 6DC00H to 6DFFFH 1B7H 75C00H to 75FFFH 1D7H 7DC00H to 7DFFFH 1F7H
66000H to 663FFH 198H 6E000H to 6E3FFH 1B8H 76000H to 763FFH 1D8H 7E000H to 7E3FFH 1F8H
66400H to 667FFH 199H 6E400H to 6E7FFH 1B9H 76400H to 767FFH 1D9H 7E400H to 7E7FFH 1F9H
66800H to 66BFFH 19AH 6E800H to 6EBFFH 1BAH 76800H to 76BFFH 1DAH 7E800H to 7EBFFH 1FAH
66C00H to 66FFFH 19BH 6EC00H to 6EFFFH 1BBH 76C00H to 76FFFH 1DBH 7EC00H to 7EFFFH 1FBH
67000H to 673FFH 19CH 6F000H to 6F3FFH 1BCH 77000H to 773FFH 1DCH 7F000H to 7F3FFH 1FCH
67400H to 677FFH 19DH 6F400H to 6F7FFH 1BDH 77400H to 777FFH 1DDH 7F400H to 7F7FFH 1FDH
67800H to 67BFFH 19EH 6F800H to 6FBFFH 1BEH 77800H to 77BFFH 1DEH 7F800H to 7FBFFH 1FEH
67C00H to 67FFFH 19FH 6FC00H to 6FFFFH 1BFH 77C00H to 77FFFH 1DFH 7FC00H to 7FFFFH 1FFH
