RL78/G13 CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 263
Sep 22, 2011
(4) Port input mode registers (PIM0, PIM1, PIM4, PIM5, PIM8, PIM14)
These registers set the input buffer of P01, P03, P04, P10, P11, P13 to P17, P43, P44, P53 to P55, P80, P81, P142,
and P143 in 1-bit units.
TTL input buffer can be selected during serial communication with an external device of the different potential.
These registers can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears these registers to 00H.
Figure 4-68. Format of Port Input Mode Register (128-pin products)
Symbol 7 6 5 4 3 2 1 0 Address After reset R/W
PIM0 0 0 0 PIM04 PIM03 0 PIM01 0 F0040H 00H R/W
PIM1 PIM17 PIM16 PIM15 PIM14 PIM13 0 PIM11 PIM10 F0041H 00H R/W
PIM4 0 0 0 PIM44 PIM43 0 0 0 F0044H 00H R/W
PIM5 0 0 PIM55 PIM54 PIM53 0 0 0 F0045H 00H R/W
PIM8 0 0 0 0 0 0 PIM81 PIM80 F0048H 00H R/W
PIM14 0 0 0 0 PIM143 PM142 0 0 F004EH 00H R/W
PIMmn
Pmn pin input buffer selection
(m = 0, 1, 4, 5, 8, 14; n = 0 to 7)
0 Normal input buffer
1 TTL input buffer
To Next Page
