(6) Port mode control registers (PMC0, PMC3, PMC10, PMC11, PMC12, PMC14)
These registers set the P00 to P03, P35 to P37, P100, P115 to P117, P120, and P147 digital I/O/analog input in 1-bit
units.
These registers can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears these registers to FFH.
Figure 4-70. Format of Port Mode Control Register
Symbol 7 6 5 4 3 2 1 0 Address After reset R/W
PMC0 1 1 1 1
PMC03
Note 2
PMC02
Note 2
PMC01
Note 1
PMC00
Note 1
F0060H FFH R/W
PMC3
PMC37
Note 3
PMC36
Note 3
PMC35
Note 3
1 1 1 1 1 F0063H FFH R/W
PMC10 1 1 1 1 1 1 1
PMC100
Note 4
F006AH FFH R/W
PMC11
PMC117
Note 3
PMC116
Note 3
PMC115
Note 3
1 1 1 1 1 F006BH FFH R/W
PMC12 1 1 1 1 1 1 1
PMC120
Note 5
F006CH FFH R/W
PMC14
PMC147
Note 6
1 1 1 1 1 1 1 F006EH FFH R/W
PMCmn
Pmn pin digital I/O/analog input selection
(m = 0, 3, 10 to 12, 14; n = 0 to 3, 5 to 7)
0 Digital I/O (alternate function other than analog input)
1 Analog input
Notes 1. 20-, 24-, 25, 30-, 32-pin products only
2. 52-, 64-, 80-, 100, 128-pin products only
3. 128-pin products only
4. 80-, 100-, 128-pin products only
5. 30-, 32-, 36-, 40-, 44-, 48-, 52-, 64-, 80-, 100, 128-pin products only
6. All products
