RL78/G13 CHAPTER 6 TIMER ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 348
Sep 22, 2011
(8) Timer input select register 0 (TIS0)
The TIS0 register is used to select the channel 5 of unit 0 timer input..
The TIS0 register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 6-13. Format of Timer Input Select register 0 (TIS0)
Address: F0074H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
TIS0 0 0 0 0 0 TIS02 TIS01 TIS00
TIS02 TIS01 TIS00 Selection of timer input used with channel 5
0 0 0
0 0 1
0 1 0
0 1 1
Input signal of timer input pin (TI05)
1 0 0 Low-speed on-chip oscillator clock (fIL)
1 0 1 Subsystem clock (fSUB)
Other than above Setting prohibited
