RL78/G13 CHAPTER 6 TIMER ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 350
Sep 22, 2011
(10) Timer output register m (TOm)
The TOm register is a buffer register of timer output of each channel.
The value of each bit in this register is output from the timer output pin (TOmn) of each channel.
The TOmn bit oh this register can be rewritten by software only when timer output is disabled (TOEmn = 0). When
timer output is enabled (TOEmn = 1), rewriting this register by software is ignored, and the value is changed only
by the timer operation.
To use the P00/TI00, P01/TO00, P16/TI01/TO01, P17/TI02/TO02, P31/TI03/TO03, P42/TI04/TO04,
P46/TI05/TO05, P102/TI06/TO06, P145/TI07/TO07, P64/TI10/TO10, P65/TI11/TO11, P66/TI12/TO12,
P67/TI13/TO13, P103/TI14/TO14, P104/TI15/TO15, P105/TI16/TO16, or P106/TI17/TO17 pin as a port function
pin, set the corresponding TOmn bit to “0”.
The TOm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the TOm register can be set with an 8-bit memory manipulation instruction with TOmL.
Reset signal generation clears this register to 0000H.
Figure 6-15. Format of Timer Output register m (TOm)
Address: F01B8H, F01B9H (TO0), F01F8H, F01F9H (TO1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TOm 0 0 0 0 0 0 0 0
TOm
7
TOm
6
TOm
5
TOm
4
TOm
3
TOm
2
TOm
1
TOm
0
TOm
n
Timer output of channel n
0 Timer output value is “0”.
1 Timer output value is “1”.
Caution Be sure to clear bits 15 to 8 to “0”.
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0 to 7)
