RL78/G13 CHAPTER 6 TIMER ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 353
Sep 22, 2011
(13) Input switch control register (ISC)
The ISC1 and ISC0 bits of the ISC register are used to implement LIN-bus communication operation by using
channel 7 in association with the serial array unit. When the ISC1 bit is set to 1, the input signal of the serial data
input pin (RxD2) is selected as a timer input signal.
The ISC register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 6-18. Format of Input Switch Control Register (ISC)
Address: F0073H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ISC 0 0 0 0 0 0 ISC1 ISC0
ISC1 Switching channel 7 input of timer array unit
0 30, 32, 36, 40, 44, 48, 52, 64, 80, 100, and 128-pin products:
Uses the input signal of the TI07 pin as a timer input (normal operation).
20, 24, 25-pin products:
Do not use a timer input signal for channel 7.
1
Input signal of the R
XD2 pin is used as timer input (detects the wakeup signal and measures the low
width of the sync break field and the pulse width of the sync field).
Setting is prohibited in the 20, 24, and 25-pin products.
ISC0 Switching external interrupt (INTP0) input
0 Uses the input signal of the INTP0 pin as an external interrupt (normal operation).
1 Uses the input signal of the RXD2 pin as an external interrupt (wakeup signal detection).
Caution Be sure to clear bits 7 to 2 to “0”.
Remark When the LIN-bus communication function is used, select the input signal of the RxD2 pin by setting
ISC1 to 1.
